Unlocking Business Potential with Process Mining: A Data-Driven Revolution

Process Mining Blog 1.jpg

Successful organizations are built on strong, well-defined processes. Just as data drives decision-making, effective processes ensure operational efficiency, scalability, and continuous improvement. The difference between high-performing companies and those struggling to grow often lies in the maturity and adaptability of their process frameworks. However, many organizations face a critical challenge: when attempting to automate or optimize workflows, they discover that process documentation is either missing, outdated, or too vague to be actionable. This gap creates inefficiencies, delays, and unnecessary costs.

This is where process mining and BPMN (business process model and notation) provide powerful solutions. Process mining helps analyze existing workflows by extracting insights from event logs, while BPMN offers a standardized method for modeling and improving processes. Together, they enable businesses to identify bottlenecks and implement data-driven optimizations. Before adopting these methodologies, it’s essential to understand their principles, applications, and benefits. In the following sections, we’ll explore how these tools work and how they can transform your business processes.

What is Process Mining?

Process mining helps you discover, monitor, and improve real processes by extracting information from event logs available in every information system today. It plays the role of a bridge between model-based process analysis (e.g., BPMN) and data-centric analysis, such as machine learning and data mining.

How Does Process Mining Work?

You can think of process mining as a type of machine learning that comprises various parts. These are as follows:

  • Event logs

  • Process discovery

  • Conformance checking

  • Enhancement

We will explain all these parts in detail so you can gain a better understanding of how process mining is used.

Event Logs

Before you recreate the process diagram, it is important to understand its lifecycle. The first step is to gather information from event logs regarding every task involved in the process. Event logs provide details about every event that occurs in an organization, including information such as the case ID, activity name, timestamp, and other additional attributes.

Case ID, activity name, and timestamps are of particular importance in process mining. These logs can be extracted from ERP systems (e.g., SAP, Oracle), CRM platforms (e.g., Salesforce), or workflow management tools by using APIs, databases, or system interfaces.

Once the logs are extracted, you need to prepare them by removing duplicated information, managing missing values, and clearing inaccuracies to ensure reliability. The logs must include all the relevant information, such as a unique case ID, activity name, timestamps, resource information, and performance metrics. In short, data hygiene corresponds directly to process mining's success.

Process Discovery

Once we have the event logs, the process can be recreated by applying the process discovery technique. This method involves creating a process model from event logs by analyzing the sequence and relationship between activities using different algorithms, such as the Alpha algorithm combined with Heuristic mining, or Inductive mining for visualizing comprehensive process models.

Visualization offers a pathway to processing maps, a simple flow chart that gives an overview of the activity sequence. On the other hand, a BPMN diagram offers a detailed representation of processes. For further in-depth analysis, Petri nets can be a viable solution.

Conformance Checking

The process visualization enables us to carry out conformance checking. The technique compares observed behavior with expected behavior as defined in the process model. The comparison provides crucial information, such as whether processes are being followed as intended or if any deviations have occurred, along with information about common non-compliance patterns.

The benefits of conformance checking include:

  • Adherence to policies and regulations

  • Identifying deviations

  • Improving process efficiency

  • Enhancing the quality of the processes

Several techniques can be used for conformance checking. These include token-based replay, alignment-based checking, and log skeleton analysis. Let’s talk about each of these techniques briefly.

  • Token-based replay simulates process model execution and tracking deviations with intuitive visualization. However, it's not effective for large datasets.

  • Alignment-based checking offers a detailed and precise analysis, measuring the cost of deviations by aligning observed behavior with expected outcomes. The only limitation is the requirement for significant computational power.

  • Log skeletons help to detect and analyze discrepancies, offering both visual and mathematical representations of process behavior.

To ensure effective process analysis, you need to maintain an accurate and updated model while prioritizing critical activities and iterating for refinement with stakeholder feedback. For continuous improvement and optimal implementation, ensure you balance computational efficiency with analysis depth.

Enhancement

The completion of conformance checking leads to the beginning of the enhancement phase. This phase focuses on improving existing process models with the help of extracted data from event logs. Enhancement includes performance analysis with the help of performance metrics, along with predictive analysis. Predictive analysis utilizes historical data to predict future behaviors with the help of predictive models. The accuracy of historical data complements machine learning model training, offering effective predictive models.

The Challenges of Process Mining

Although process mining is an effective technique, it comes with its unique challenges. For example, the accuracy depends heavily on the quality of event logs. As such, data cleanliness is necessary for accurate conclusions. Secondly, the complexity of real-world business processes requires sophisticated tools and techniques. Last but not least, implementing improvements based on process mining insights requires effective change management practices.

Achieve End-to-End Visibility

Process mining uses real event data to reveal how processes actually work, helping businesses spot inefficiencies, improve workflows, and ensure compliance. It provides clear, unbiased insights and end-to-end visibility, enabling continuous optimization and better decision-making.

The creation of a BPMN diagram is the most important output of process discovery. A BPMN engine, for example, Flowable, can read and run these diagrams, supporting the modeling and management of complex processes that require a case-based approach. Flowable can also integrate with artificial intelligence, which can optimize processes in record time.

Marcos Dominguez

Marcos Dominguez is a Software Engineer based in Munich with over 15 years of experience. Throughout his career, he has successfully automated a wide range of processes, delivering significant time and cost savings.
